4G LTE Wireless GPS Tracker With Temperature/Humidity Sensot For Cold Chain (GPT45TH)

Manufacturer:	Eelink
Demension:	95(L)X55.5(W)X22.7(H)
Color:	Case Grey/Rubber Yellow
Location:	ShenZhen,CHINA
GNSS Band:	GPS/BDS/GLONASS
Battery:	2600mAH
Voltage:	3.0-4.2V(battery)
Network Type:	LTE-FDD/LTE -TDD/GSM
USB Interface:	Type-C
SIM Card:	Mini-SIM

GPT45TH is 4G rechargeable GPS tracking Device, it can connect an external temp and humidity probe for temperature monitoring for cold chain.

It has a wide range of industrial and commercial applications, built-in high-capacity battery, light sensor , IP65 level waterproof. It is also wireless portable GPS tracker, can be expanded with multiple functions.

Inquiry Us + Sample Order

Description Accessories

Description of GPT45

4G LTE CAT1 portable GPS tracker is a wireless solution for real-time tracking. Featuring Geo-fence alarms, it can expand to include an internal temperature sensor and an external humidity probe version. It has motion sensors, light sensors, and air pressure sensor, the ability to protect vehicle positioning and asset tracking, this device offers comprehensive monitoring and security measures. Also, it provide users standardized or customized system solutions, intelligent monitoring to meet the needs of different industries.

The device can be used in major industries include:

-1.Portable tracker for personal tracking

-2.Automotive Risk Control

-3. Fleet management

-4. Logistics Transportation

-5.Cold chain Monitoring

-6. Asset tracking

FUNCTION:

■ Speed Alarm
■ Geo-fence Alarm
■ Low Battery Alarm
■ Real-time Tracking
■ Route Play Back
■ Temperature Alarm

■ Built-in light sensor for opening door detection

■ Crash/Falling/ Vibration/Speed Alarm

Features:

Demension	95x55.5x22.7mm
LED	GPS(Blue),GSM/LTE(Red)
Battery	2600mAh
Antenna	Built-in LTE/GSM antenna, ceramic GPS antenna
LTE Band	LTE-FDD:B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/B18/B19/B20/B25/B26/B28/B66 LTE-TDD: B34/B38/B39/B40/B41
GSM Band	GSM850/EGSM900/DCS1800/PCS1900
GPS Accuracy	5-15m(depend on GPS signal)
LBS Accuracy	>200m
GNSS	GPS/BDS/GLONASS

■ Support Global 4G LTE CAT1 FDD&TDD, GSM network

■ Support GPS/ Beidou/ Glonass. A-GNSS/ LBS for aiding.

■ Real time tracking,data uploaded by GPRS regularly, check by Web/APP/SMS

■ Web Tracking Service Platform, Mobile phone APP Client, SMS query
■ Low battery alarm,GEO-fence, Speed alarm
■ Built in Motion sensor, support various alarm.
■2600 mAh lithium battery, low battery alarm .
■ Waterproof IP65 level and dust proof, vehicle/ individual /cold chain/asset are applicable.
■ Eelink 2.0 protocol, multiple protocol support, can be integrated to platform of customers.

■ OTA upgrade firmware.

■USB connect with PC to configure device

■ Expansion(customized):

built-in temperature sensor

connect to temperature/humidity probe

■Built-in Air pressure sensor to read the current air pressure data

■Built-in light sensor for detecting door open

Optional Accessories:

Temperature probe (PT100)

Temperature/humidity probe
