4G LTE iButton tracking device use for identify driver ID in fleet management
4G LTE iButton tracking device use for identify driver ID in fleet management 4G LTE iButton tracking device use for identify driver ID in fleet management 4G LTE iButton tracking device use for identify driver ID in fleet management
  • 4G LTE iButton tracking device use for identify driver ID in fleet management

  • Manufacturer: Eelink
    Model: TK419
    Working Network: 4G LTE CAT1,fallback to 3G and 2G
    Working Voltage: 9-72V

    The upgrade smart 4G car tracker TK419 is with more functions than the traditional tracker.

    Tk419 is a 4G Ibutton tracking device,integrated Ibutton reader to identify the authorized driver.

    The 4G Ibutton tracking device support full FDD network, FDD: B1/B2/B3/B4/B5/B7/B8/B28, fallback 3G/ 2G, use worldwide.


  • $42.00
  • - +
  • Inquiry Us + Sample Order
  • Description Features Specifications Accessories

    What is the IButton device


    Generally speaking,an iButton device have stainless steel 'can' as an electronic communications interface. Each can has a data contact, called the 'lid', and a ground contact, called the 'base'. Each of these contacts is connected to the silicon chip inside. The lid is the top of the can; the base forms the sides and the bottom of the can and includes a flange to simplify attaching the iButton device to related device like GPS tracker.

    IButton device can be use in many fields,for example:

    4G IButton Tracking device usege in fleet management

    4G IButton Tracking device usege in Asset tracking

    4G IButton Tracking device use in supply chain management

    More introduction ABOUT iBUTTON

    We will mainly describe that the application of iBUTTON devices in GPS fleet tracking.Why Ibuttons is important for GPS tracker ?What is Benefits when you gps tracking devices integrated with IButton? How do iButton work in GPS tracking?

    The iButton device is ideal for Identifying Authorized driver.A tracking device,integrated with IButton will have more uses such as finding stolen vehicles, creating automatic vehicle logs, and managing a fleet of trucks and buses .

    Installing the GPS TRACKER with ibutton is a simple way to track the location of a vehicle and identify whether it has an authorized driver.

    Usually,the IButton tracking device consist of many complex parts below:

    1.GPS receiver to provides information about the location of the objects.

    2.GSM module that used to send SMS (text messages) to a pre-programmed mobile number.

    3.iButton unit . The iButton unit to identify authorized drivers.

    4.SOFTWARE AND PLATFORM.If you want to view data through your phone and APP, then you also need software and a server that cache and transfer the data.



    All in all, the make IButton tracking device works well, which requires software and hardware technology to work together. It is a complex system of components.The more function the device has, the more components you need.

    How do iButton work in GPS tracking


    In engine off state,device set the engine in circuit off state. When you want to start the engine of vehicle,you should have a IButton ID to pass the verification by place iButton reader on  the iButton devices. After iButton authorized,you can start the car engine after 2 minutes,If you dont be authorized,no the IButton ID on you own, you are not able to start the engine.

    What is Benefits when you gps tracking devices integrated with IButton


    1.Manage fleet drivers betterly to know more details of all iButton tracking devices

    Authorize driver can start the vehicle engine and their route trajectory will be recorded . Both authorized and unauthorized driver iButton ID would be transmitted onto server as records,which get more datas to guide the driver's behevior.

    2.Cache more history data,and start your car easy

    Onces you pass the iBUTTON verification,you can drive you car right now,you will save much time.
    If the vehicle driver pass the iButton ID verification, the iButton data would be sent to server. If driver doesn't start the engine, it would get into NO-start-engine mode. The history data will be cache. So we can know how more car are working easily.

    3.iButton ID verification go on even in no 3G/4G signal


    If your fleet keep the authorized iButton ID in gps tracking devices, even no GSM/3G signal , the iButton ID verification part in gps tracking device would still work normally, meanwhile it will cache iButton data in memory,if 3g/4G signal work again,those data will be transfered again.

    The iButton device is the ultimate information carrier for automatic identification, secure authentication, and many portable applications.


    Why Ibuttons function is important for GPS tracker

    iButton is the technology used by most major fleet operators to identify the drivers in each vehicle of the fleet.

    A GPS tracker integrated Ibuttons will be benefits for the driver‘s safety.For companies with large fleets, it is important to ensure driver safety and to identify certified employees.


    How does iButton works for Driver Identification


    The operation of iButtons is simple yet very effective:

    A distinctive key fob is assigned to each driver.A reader is installed in the vehicle which is connected to the GPS tracking device.When the driver starts the vehicle he is required to present the key fob to the key reader. This associates him with that vehicle.A LED light gives feed back to the driver that the key has been accepted



    Automatically logs and reports all driver activity

    Powerful reports are then generated from this collected data. Reports can be run by vehicle or driver for any length of time containing times of log in and outs along with durations.

    The reports will tell you more details including :

    1.Daily detail of the time when drivers start and finish the task

    2.How many hours worked per day, week, month.

    3.Since the iButton logs out the driver after each long stop (predefined by you), you'll learn more about the daily routine of each one of your drivers.

    4.You can also generate summary reports with total hours worked.

    5.Worked hours report per driver can be exported to excel for further analysis

    IBUTTON is a solution for fleet management tracking


    1,  Driver authorization – gives ability to use vehicle only for specific iButton owners and identify which driver is on the road.

    2,  Immobilizer – without iButton authorization you can not run engine starter and and use vehicle.

    3,  AutoGeofencing – gives ability to know when car leaves customized areas without iButton authorization.


    GPS tracker applications


    Eelink has designed and developed a new generation of 4G GPS tracker with iButton.

    This 4G iButton tracking devices will be your best choice for fleet tracking, supply chain tracking, asset tracking.

    Eelink TK419 4G iButton tracking devices features


      Eelink TK419 4G iButton tracking device

    4G & LTE & 3G

    Supporting 4G 3G and 2G network for a wide range of signal coverage

    4g lte icon

    Global 4G

    FDD: B1/B2/B3/B4/B5/B7/B8/B28

    TDD: B40

    WCDMA:B1/B2/B5/B8

    WCDMA network icon

    1-Wire Interface

    1-wire interface for SOS, Ibutton, and temperature sensor.

    1-Wire Interface icon

    IButton

    Can read driver ID, only authorized driver can ignite the car

    IButton icon

    Remote Cut-off (Oil/Engine)

    Compel the vehicle to stop by breaking off the fuel connection

    Remote Cut-off icon

    Smart Alarms

    Movement alarm, low battery alarm, GPS blind area alarm, power-cut alarm, GPS antenna disconnect alarm and Geo-fencing alarm

    Smart Alarms icon

    Multiple I/O Interfaces

    3 digital inputs, 2 digital outputs,1 Microphone Socket,1 Speaker Socket,1- Wire Interface

    Multiple I/Interfaces

    Tracked by: SMS,Web,APP

    Real-time tracking the location and status by SMS, Web & APP


    4G GPS Tracker TK419 Specification


    Model:TK419
    GPS Chip:UBLOX GPS, GNASS Chip
    Antenna:LTE Antenna Internal,GPS Antenna Internal
    GPS Positioning Accuracy: 5m-15m (Depending on GPS Signal)
    LBS Positioning Accuracy: ~200m (Depending on density of base stations)
    GPS Frequency L1, 1575.42MHz C/A code
    Network:LTE/FDD, WCDMA,GSM, SMS
    GSM Frequency: 850/900/1800/1900MHz
    WCDMA Frequency: W800/W850/W900/W1900/W2100 MHz
    GPS Band: 1575MHz
    GSM Band: EDGE GPRS(B2/ B3/ B5/ B8)  850, 900, 1800 and 1900MHz
    WCDMA Band: B1/B2/B5/B8
    LTE Band: FDD(B1/B2/B3/B4/B5/B7/B8/B28); TDD(B40)
    UMTS:DC-HSDPA  B1/ B2/ B5/ B8  HSUPA
    Hot/Warm/Cold Start <3x, <15s, <60s
    Main PCB: uBlox LTE Module
    Built-in Battery Embedded 3.7V/140mAh battery for emergency alarm when removing main power
    Work Current: <30 mA
    Standby Current: <15 uA
    IP Waterproof Level: IP65
    Dimensions (mm): 89mm x 37mm x 12mm
    Operating Voltage: 9-72V DC
    Environment Temperature: -20○C - 75° C
    Environment Humidity:20% ~ 80% RH
    Battery capacity:140m Ah Standby:4 Hours
    Net Weight:46g

    Optional Accessories

    Relay(optional)
    SOS Button(optional)
    External battery(optional)
    iButton probe(optional)
